WAI:61-125 IM416 24V
Slots:25
Dim: 530mm OAL 19-Splines
15.80mm Shaft OD 17.32mm Shaft OD
REPLACING: DELCO 1951254
REPLACING: DELCO 1951254
SERVICING: DELCO 1109294, 1109299, 1109632, 1109633, 1109635, 1109641, 1109644, 1109757, 1109779, 1109792, 1109793, 1109794, 1109832, 1109835, 1109849 |
WAI:61-122 IM419 12V
Slots:25
Dim:451mm OAL 19-Splines
REPLACING: DELCO 1987989
REPLACING: DELCO 1987989
SERVICING: DELCO 1990337, 1990348, 1990349, 1990352, 1990353, 1990354, 1990355, 1990356, 1990358, 1990362, 1990363, 1990365, 1990369, 1990370, 1990372
|
WAI:61-121 IM410 24V
Slots:25
Dim: 467mm OAL 19-Splines
15.80mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 1945500
REPLACING: DELCO 1945500
SERVCING: DELCO 1113818, 1113825, 1113827, 1113830, 1113831, 1113832, 1113840, 1113842, 1113845, 1113846, 1113849, 1113850, 1113851, 1113852, 1113853. |
WAI:61-144 24V
Slots:29
Dim: 391mm OAL 19-Splines
15.80mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 10472559
REPLACING: DELCO 10472559 |
 |
 |
 |
 |
WAI:61-123 IM421 24V
Slots:25
Dim: 451mm OAL 19-Splines
15.80mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 1988435
REPLACING: DELCO 1988435
SERVICING: DELCO 1990344, 1990350, 1990357, 1990359, 1990360, 1990361, 1990364, 1990367, 1990368, 1990371, 1990373, 1990378, 1990381, 1990382, 1990383 |
WAI:61-118 IM418 12V
Slots:29
Dim: 391mm OAL 3-Splines
14.22mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 1985249
REPLACING: DELCO 1985249
SERVICING: DELCO 1990308, 1990309, 1990310, 1990311, 1990312, 1990313, 1990315, 1990316, 1990317, 1990318, 1990319, 1990320, 1990321, 1990326, 1990327 |
WAI:61-139-9 12V
Slots:27
Dim: 256mm OAL 3-Splines
11.89mm Shaft OD 11.89mm Shaft OD
REPLACING: DELCO 10467582
REPLACING: DELCO 10467582, 10471537, 10495881, 10499230 |
WAI:61-8400 IM3019 12V
Slots:23
Dim: 177mm OAL 8-Splines
17mm Shaft OD 10mm Shaft OD
REPLACING: DELCO 10456466
REPLACING: DELCO 10456466, D4161
SERVICING: DELCO 10465044, 10465045, 10465046, 10465047, 10465048, 10465049, 10465050, 10465055, 10465056, 10465057, 10465058, 10479613, 10479619, 1113266, 1113267 |
 |
 |
 |
 |
WAI:61-100-9
Slots:27
Dim: 242mm OAL 3-Splines
11.89mm Shaft OD 11.89mm Shaft OD
REPLACING: DELCO 10456407
REPLACING: DELCO 10456407 |
WAI:61-137
Slots:32
Dim: 140mm OAL 24-Splines
9.50mm Shaft OD 8.00mm Shaft OD
REPLACING: DELCO 10498530, 10498586
REPLACING: DELCO 10498530, 10498586, D4151, D4152
|
WAI:61-136 12V
Slots:27
Dim: 300mm OAL6-Splines
12.37mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 1950307
REPLACING: DELCO 1950307
|
WAI:61-107 12V
Slots:23
Dim: 282mm OAL 3-Splines
11.89mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 10470773, 10498863, 1940624,
1965724,1970548
REPLACING: DELCO 10470773, 10498863, 1940624, 1965724, 1970548
|
 |
 |
 |
 |
WAI:61-145 IM3072 12V
Slots:28
Dim: 128mm OAL 16-Splines
8.00mm Shaft OD 8.00mm Shaft OD
REPLACING: 10475100
REPLACING: 10475100
SERVCING: PG150S, PG260F¹ |
WAI:61-114
352mm OAL 6-Splines
14.22mm Shaft OD 14.22mm Shaft OD
OE:1932872, 1935259, 1942244, 1967042
Replace: CARGO#:136249
HITACHI#: 2130-61004, 2130-81004
LESTER(OLD)#: 3118 |
WAI:61-133M
Slots:23
Dim: 335mm OAL 6-Splines
12.65mm Shaft OD 14.22mm Shaft OD
REPLACING: 1876366, 1949190, 1950417, 1960866
Delco 1876366, 1949190, 1950417, 1960866 |
WAI:61-124 IM414 24V
Slots:25
Dim: 483mm OAL 19-Splines
15.80mm Shaft OD 17.32mm Shaft OD
REPLACING: DELCO 1945840
REPLACING: DELCO 1945840
SERVCING: DELCO 1109220, 1109222, 1109276, 1109281, 1109282, 1109285, 1109286, 1109287, 1109288, 1109289, 1109290, 1109291, 1109292, 1109296, 1109297 |
 |
 |
 |
 |
WAI:61-143 12V
Slots:29
Dim: 391mm OAL 19-Splines
15.80mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 10473852
REPLACING: DELCO 10473852 |
WAI:61-120 IM409 12V
Slots:25
Dim: 467mm OAL 19-Splines
15.80mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 1945906, 1952530, 1961320
REPLACING: DELCO 1945906, 1952530, 1961320
SERVICING: DELCO 1114047, 1114051, 1114052, 1114054, 1114055, 1114056, 1114057, 1114058, 1114059, 1114061, 1114062, 1114063, 1114064, 1114065, 1114066 |
WAI:61-119 IM420 24V
Slots:29
Dim: 391mm OAL 3-Splines
14.22mm Shaft OD 14.22mm Shaft OD
REPLACING: DELCO 1988322
REPLACING: DELCO 1988322
SERVCING: DELCO 1990330,1990331, 1990332,1990499, 1993701,1993702, 1993707,1993723, 1993729,1993732, 1993741,1993742, 1993744, 1993831 |
WAI:61-139 12V
Slots:27
Dim: 256mm OAL 3-Splines
11.89mm Shaft OD 11.89mm Shaft OD
REPLACING: DELCO 10467708
REPLACING: DELCO 10467708 |
 |
 |
 |
 |
WAI:61-8401 IM3018 24V
Slots:23
Dim: 177mm OAL 8-Splines
17mm Shaft OD 10mm Shaft OD
REPLACING: DELCO 10457117, 10455502, 1113272, 1113277, 1113291
REPLACING: DELCO 10457117
SERVICING: DELCO 10455500, 10455502, 1113272, 1113277, 1113291 |
WAI:61-132
Slots:27
Dim: 256mm OAL 3-Splines
11.07mm Shaft OD 11.07mm Shaft OD
REPLACING: DELCO 10471537, 10495881,
REPLACING: DELCO 10471537,
10495881, D4141, D4146, D4150,
D4160 |
WAI :39MT
Slots:21
Dim: 195mm OAL 14-Splines
12mm Shaft OD 12mm Shaft OD
WAI:61-151 12 Volt
Unit Nos: Delco 8200037; 19011514, 516, 517, 518, 521, 531
Lester Nos: 6802, 04, 06, 14, 18, 22
|
29MT 61-158
Slots:23
Dim: 161.5mm OAL 12-Splines
10.00mm Shaft OD 10.00mm Shaft OD
Unit Nos: Delco 8200010, 8200011,
8200067, 19011400, 19011402, 19011403,
19011407, 19011409
Lester Nos: 6840, 6841, 6842, 6843, 6844, 6849 |
 |
 |
 |
 |
WAI:61-138 IM3065
Slots:32
Dim: 140mm OAL 31-Splines
9.50mm Shaft OD 8.00mm Shaft OD
REPLACING: DELCO 10498616
REPLACING: DELCO 10498616
SERVCING: PG200,PG250
|
WAI:61-146
Slots:25
Dim: 143.5mm OAL 11-Splines
10.00mm Shaft OD 10.00mm Shaft OD
REPLACING:DELCO 9000836, 9000841, 9000854, 9000857, 9000858, 24506694
REPLACING:DELCO 9000836, 9000841, 9000854, 9000857, 9000858, 24506694 |
WAI:61-140 /IM3064 12V
Slots:21
Dim: 121mm OAL 12-Splines
7.97mm Shaft OD 9.75mm Shaft OD
REPLACING: 10475588
REPLACING: 10475588
SERVCING: PG260M |
WAI:61-133 12V
Slots:23
Dim: 335mm OAL 6-Splines
12.65mm Shaft OD 14.22mm Shaft OD
REPLACING: 1876366, 1949190, 1950417, 1960866
REPLACING:
1876366, 1949190, 1950417, 1960866 |
 |
|
|
|
WAI:61-115
394mm OAL
3-Splines
14.22mm Shaft OD 14.22mm Shaft OD
REPLACING: 1948999, 1967045
REPLACING:
1948999, 1967045 |
|
|
