LUCAS Armature
WAI:61-9204 IM220
Slots:21
Dim:330mm OAL 9-Splines
16.97mm Shaft OD 12.65mm Shaft OD
REPLACING: 54243592
REPLACING: 54243592
SERVCING: 26336, 26342, 26349, 26363, 26384, 26398, 26416, 26421, 26428, 26429, 26433, 26435 |
IM43 12V
Slots:19
L:250mm O.D:54.3mm
REPLACING: 4142225, 4198600, 4202983, 4255494, 74861761
REPLACING: 4142225, 4198600, 4202983,
4255494,74861761
SERVCING:
4142222, 4143828, 4152196, 4198226, 4198600, 4229113, 4229114, 4474805 |
WAI:61-9205 IM211
Slots:21
Dim:303mm OAL 12-Splines
16.97mm Shaft OD 12.65mm Shaft OD
REPLACING: 54268382
REPLACING: 54268382
SERVCING:
27500, 27515, 27516, 27518, 27519, 27528,
27536, 27539, 27540, 27541, 27553, 27554,
27565, 27569, 27572
|
IM608 12V
Slots:12
Teeth:12 L:119mm O.D:54mm
REPLACING: 54290870,TGB125
REPLACING: 54290870,TGB125
SERVCING:
26800, 26801, 26804, 26814, 26812, 26820,
26823, 26824, 26834, 26837, 26842, 26843
|
 |
 |
|
|
LUCAS Armature
WAI:61-9203 IM218
Slots:21
Dim:303mm OAL 12-Splines
16.97mm Shaft OD 12.65mm Shaft OD
REPLACING:26211, 26227, 26246, 26265, 26274, 26291
REPLACING:
26211, 26227, 26246, 26265, 26274, 26291,
26294, 26295, 26304, 26312, 26316, 26323,
26338, 26339, 26341, 26343, 26345, 26351,
26352, 26357, 26358, 26359, 26366, 26369
|
IM328 12v
Slots:33
L:221.5mm O.D:60mm
REPLACING: 9001184001
REPLACING: 9001184001 |
|
| |
